Cranial Drill Attachment
Cranial Drill Attachment
Cranial Drill Attachment (4)
Cranial Drill Attachment (7)

Cranial Drill Attachment

Cranial Drill Attachment
Daim Ntawv Thov: Kev phais mob & Kev phais Orthopedic
Khoom siv: Stainless hlau 304
Kev kam rau siab: +/-0.01mm
Kev tsim khoom: 5-axis CNC Machining
Cov chaw: Nyiv Mazak QTE-100MSYL

Xa kev nug

Tsham tam sim no

Hauj lwm lawm

Kev tsis

Cranial Drill Attachment

Dab tsi yog Cranial Drill Attachment?

Cranial Drill Attachment yog ib qho cuab yeej tshwj xeeb uas siv nrog cranial drills hauv neurosurgery thiab lwm yam txheej txheem. Nws yog ib qho tseem ceeb rau kev tswj xyuas qhov drilling, tsim cov ntsiab lus nkag, lossis kev ruaj ntseg hauv cov pob txha cranial. Cov ntawv txuas no txhawb kev hloov kho qhov loj me thiab tsim kom tau raws li cov kev xav tau ntawm kev phais tshwj xeeb. Ua nrog cov ntaub ntawv siab heev, nws yog sib xws nrog cov lus qhia pins thiab cov khoom tshwj xeeb rau kev ua tau zoo.

Cranial Drills yog siv thaum xav tau craniotomy rau tso intracranial siab (ICP) saib xyuas cov cuab yeej lossis cov kua dej cerebrospinal. Shenzhen Pride Industrial Co. Ltd. muab cov kev daws teeb meem rau Cranial Drill Attachments los txhawb cov ntawv thov tseem ceeb no.

Cranial Drill Function

Cranial Drill, tseem hu ua craniotome, yog ib qho cuab yeej tshwj xeeb uas siv hauv kev phais mob hlwb. Nws lub luag haujlwm tseem ceeb yog los tsim kev tswj qhov qhib hauv pob txha taub hau, xws li burr qhov (trepanation) lossis qhov qhib loj dua rau cov txheej txheem xws li craniotomy thiab craniectomy. Cov kev qhib no muab nkag mus rau lub hlwb rau ntau yam kev phais.

Kev xyaum yog qhov tseem ceeb rau kev tso cov cuab yeej xws li intracranial siab (ICP) saib lossis cov kua dej cerebrospinal. Nrog cov yam ntxwv siab heev, Cranial Drill txo qis kev puas tsuaj rau cov ntaub so ntswg ib puag ncig, ua rau nws yog ib qho tseem ceeb hauv kev phais hlwb.

Cranial Drill Attachment 5

Cranial Drill Attachment Product Specifications

Cranial Drill Attachment yog tsim los rau ntau yam kev phais. Nws yog qhov zoo tagnrho rau cov pob txha pob txha nyias, cov pob txha tsis sib xws, thiab cov txheej txheem menyuam yaus. Cov perforators no yog compact, neeg siv-phooj ywg, thiab txo qhov kev pheej hmoo ntawm kev nkag mus txaus ntshai. Cov yam ntxwv tseem ceeb suav nrog cov npoo ntse rau kev txiav du nrog lub siab tsawg. Lub taub hau tsis-skid tiv thaiv zawv zawg ntawm pob txha taub hau thaum pib. Lub laum sab hauv tsim cov pob txha pob txha los tiv thaiv dura.Ob qho kev xaiv rov siv tau thiab pov tseg yog muaj. Standard qhov ntau thiab tsawg suav nrog14mm / 11mm thiab 11mm / 7mmqauv. Ib tug tshwj xeeb version muaj ib tug14 hli txheej laum thiab 9 hli puab xyaum. Qhov no muab lub txee ruaj khov thiab cov pob txha tuab dua rau kev tiv thaiv ntxiv ntawm cov pob txha tsis sib xws.

Pride muab tag nrho customization ntawm cranial perforators. Cov ntaub ntawv muaj xws li stainless hlau thiab kev kho mob-qib titanium alloys. Txhua yam khoom sib ntsibGB 24627 thiab ASTM F2063 tus qauv, xyuas kom muaj kev nyab xeeb thiab durability.Cov kev txwv no yog rau siv; peb muab tag nrho customization kom tau raws li koj cov kev xav tau tshwj xeeb, suav nrog kev xaiv cov khoom, tsim qauv, thiab cov txheej txheem machining. Kev ntim ntim yog muaj raws li qhov kev thov.

Khoom kos duab

Cranial Drill Attachment 10

Cranial Drill Attachment 4

Cranial Drill Attachment

Khoom npe	Cranial Drill Attachment
Daim ntawv thov	Cov cuab yeej fais fab rau Orthopedic phais
Khoom siv	Kev kho mob Stainless hlau
Hardness	NRB 92 (SS304)
Muaj nuj nqi	Tapping
Cov duab	Ncaj
Roughness	Ra<0.4um
Drill ceev	800rpm ib
Txoj kab uas hla	9-14 hli
Ua siab ntev	+/{1}}.01mm
Lwm yam ntxwv	High Wear Resistance, Kub-resistant
Kev tsim khoom	Sliding Headstock Tshuab dhos, 5-Axis CNC Machining
Daim ntawv pov thawj	ISO 9001: 2015, ISO 13485
Cov chaw	Nyiv Mazak QTE-100MSYL, Citizen Cincom L12-1M7
Kev thauj mus los	FedEx, DHL, TNT, EMS, thiab lwm yam.
Ntim	PP hnab los yog tailor-made packing ntawm kev thov

Cranial laum qhov ntau thiab tsawg pab kev phais sib txawv. Qhov loj dua (piv txwv li, 14mm / 11mm) yog qhov zoo tagnrho rau cov neeg laus cov neeg mob lossis cov txheej txheem uas xav tau kev qhib dav dua, xws li kev kho mob cranial lossis cog cog. Qhov me me (piv txwv li, 11mm / 7mm lossis xyaum nrog 9mm puab txoj kab uas hla) yog haum rau cov neeg mob me los yog cov pob txha taub hau nyias, muab qhov tseeb rau kev ua haujlwm me me.

Kev xyaum me me tsim cov pob txha tuab dua, txhim khu kev tiv thaiv dura, tshwj xeeb tshaj yog rau ntawm qhov tsis sib xws. Lawv muab kev tswj zoo dua rau qhov nqaim lossis nkhaus tab sis xav tau kev phais ntau dua. Hauv qhov sib piv, kev xyaum loj dua txiav sai dua thiab txo lub sijhawm ua haujlwm tab sis xav kom ceev faj kom tsis txhob muaj teeb meem. Lawv zoo dua rau qhov qhib ncaj thiab qhov chaw raug loj. Txhua qhov sib npaug sib npaug ceev, precision, thiab kev nyab xeeb, haum rau cov kev siv phais tshwj xeeb.

Cranial Drill Attachment 6

Manufacturing txheej txheem rauCannulated Drill Attachment

Cranial Drill Attachment yog tsim los siv cov txheej txheem siab heev thiab meej. Cov txheej txheem suav nrog 5-axis CNC machining thiab Swiss-type machining rau kev ua haujlwm xws li milling, drilling, thiab tig. Cov khoom siv high-end, xws li covMazak QTE-100MSYL thiab Citizen Cincom L12-1M7, xyuas kom superior zoo.

Tight tolerances ntawm+/{1}}.01mmyog khaws cia, nrog nto roughness tswj ntawmRa < 0.4um. Cov ntaub ntawv raug xaiv ua tib zoo xaiv thiab ua tiav kom ua tau raws li cov qauv nruj rau kev nyab xeeb thiab kev ua haujlwm. Ntau yam kev kho saum npoo yog siv los txhim kho cov khoom kawg. Cov no suav nrog polishing, electropolishing, ultrasonic tu, acid etching, thiab passivation. Electropolishing refines saum npoo thiab txhim kho kev tiv thaiv corrosion. Ultrasonic tu zoo tshem tawm cov kab mob ntawm qhov chaw nyuaj.

Txheej Txheem Flow

Cheebtsam	Txheej Txheem Flow	Lub npe txheej txheem	Tshuab siv	Tshuab Hom	Cov cuab yeej tshuaj xyuas
Cranial Drill Attachment	1	Nkag los	N/A	N/A	1. Pin gauge 2. Calipers
	2	Milling	5-axis CNC tshuab	Mazak QTE-100MSYL	Qhov projectors
	3	Tig	5-axis CNC tshuab	Mazak QTE-100MSYL	Qhov projectors
	4	Drilling	5-axis CNC tshuab	Mazak QTE-100MSYL	Qhov projectors
	5	Electrolytic polishing	N/A	N/A
	6	Ultrasonic tu	N/A	N/A
	7	Kev tshuaj xyuas & ntim	N/A	N/A

Video ntawmCNCKev tsim khoom

Tshawb nrhiav lub ntiaj teb ntawm CNC kev tsim khoom hauv kev nqis tes ua! Daim vis dis aus no muab kev saib sai rau hauv peb cov txheej txheem, ib kauj ruam ntawm kauj ruam. Saib cov ntaub ntawv raw hloov mus rau qhov tseeb, tiav lawm. Saib xyuas cov tshuab ua haujlwm siab heev thiab txawj ua haujlwm ntawm tes. Xav paub txog peb cov khoom siv tes ua? Nyem rau saib daim video tag nrho!

Cranial Drill Attachment 9

Customized Services rauCannulated Drill Attachment

Peb muab customization rau tag nrho cov khoom ntawm cranial laum attachments. Qhov no suav nrog lub cev, ncej, taub hau, latch, ntsia liaj qhov rooj, kabmob, O-ring, thiab lub nplhaib sab nraud. Peb kuj muab kev cai daws teeb meem rau lwm cov pob txha laum accessories xws li cannulated laum khoom, pob txha reamers, thiab coj pins. Txawm hais tias koj xav tau ib daim ntawv txuas ua tiav, ib qho chaw, lossis ib pawg me me ntawm cov qauv kev hloov kho, Shenzhen Pride Industrial Co. Ltd. tuaj yeem ua tiav koj qhov kev xav tau. Peb tsom mus rau kev xa tawm cov lus qhia meej, zoo, thiab kho kom haum, tsis hais qhov loj npaum li cas ntawm qhov kev thov.

FAQ

01.Dab tsi yog Cranial Laum thiab Nws Qhov Txuas Siv Rau?

Cranial laum, ua ke nrog nws qhov txuas, yog ib qho cuab yeej tshwj xeeb uas siv hauv kev phais mob hlwb los tsim cov qhov qhib meej hauv pob txha taub hau. Cov cuab yeej no tseem ceeb heev rau kev ua cov craniotomies, uas tej zaum yuav xav tau rau ntau yam, suav nrog kev kuaj mob lossis kho cov qog hlwb, txiav los yog kho cov hlab ntsha, lossis tshem cov ntshav txhaws los ntawm cov hlab ntsha. Lawv kuj tseem siv tau rau kev tso intracranial siab (ICP) saib lossis cerebrospinal kua kua system.

02.Qhov luaj li cas muaj rau Cranial Drill Attachments?

Cov qauv loj muaj xws li 14mm / 11mm thiab 11mm / 7mm qauv. Kev cai ntau thiab tsawg, xws li 14 hli txheej laum nrog 9 hli puab xyaum, kuj muaj rau cov ntawv tshwj xeeb.

03.Dab tsi yog cov khoom siv hauv kev tsim cov khoom sib txuas no?

Lawv feem ntau yog ua los ntawm kev kho mob-qib stainless hlau lossis titanium alloys. Cov ntaub ntawv no ua tau raws li GB 24627 thiab ASTM F2063 tus qauv, ua kom muaj kev nyab xeeb thiab kav ntev.

04.Puas yog Cranial Drill Attachments rov siv tau lossis pov tseg?

Ob qho kev xaiv muaj. Reusable attachments yog tsim los rau ntau yam kev siv nrog kom tsis muaj menyuam, thaum cov khoom siv pov tseg yog npaj rau kev siv ib zaug kom huv si.

05.Cov kev kho deg twg yog siv rau Cranial Drill Attachments?

Kev kho deg muaj xws li electropolishing, ultrasonic tu, acid etching, thiab passivation. Cov txheej txheem no txhim kho corrosion kuj, smoothness, thiab tag nrho cov zoo.

06.Cov Cranial Drill Attachments puas tuaj yeem kho tau?

Yog lawm, Pride muaj kev hloov kho tag nrho. Cov duab, qhov loj me, thiab cov yam ntxwv tshwj xeeb tuaj yeem hloov kho kom tau raws li qhov tshwj xeeb ntawm kev phais.

Tiv tauj peb tam sim no

Shenzhen Pride Industrial Co. Ltd. tshwj xeeb hauv kev tsim cov khoom siv kho mob zoo thiab cov cuab yeej hluav taws xob. Lawv tsim cov cuab yeej orthopedic thiab neurosurgical, nrog rau cov pob txha xyaum, cranial xyaum, thiab lwm yam cuab yeej phais. Cov cuab yeej no yog tsim los rau ntau yam txheej txheem xws li orthopedic, txha nraub qaum, thiab kev phais yas.

Cov khoom lag luam yog tsim los tiv thaiv qhov kub thiab txias siab kom tsis muaj menyuam. Customizable kev daws teeb meem yog muab los ua kom tau raws li cov kev xav tau ntawm kev phais tshwj xeeb. Precision, kev nyab xeeb, thiab kev ua haujlwm yog qhov tseem ceeb hauv lawv cov txheej txheem tsim thiab tsim khoom.
